Features/Functions
WiFi6 compatible.
WiFi6 is approximately 1.4 times faster than the previous IEEE802.11ac (WiFi5) and has approximately four times the network capacity, allowing multiple clients to transfer data simultaneously at higher speeds.
Stable operation.
The WiNG firmware shares endpoint information between APs, with a Roaming Assist feature that, depending on configuration, has the ability to detect signal strength attenuation and disconnect from the AP when a certain distance is exceeded, facilitating smooth roaming.
Multiple units can be managed centrally
The Virtual Controller function allows configuration information for up to 64 AP310e units with the same firmware version to be managed centrally.
Product Specification
| Specifications/model number | AP310e（External antenna models） |
|---|---|
| Wi-Fi Alliance | 802.11a/b/g/n/ac/ax |
| Interface | IEEE802.3 Gigahit Ethernet x 2, USB 3.0 x 1 (Type A, 0.5A) |
| PoE input. | GE1 port 802.3af / 802.3at |
| PoE output | GE2 port 802.3af (GE1 input 802.3at required) |
| Active channel | 2.4 GHz: channels 1 to 13 5.2 GHz: channels 36 to 140 |
| Antenna board | 4 ports (for wireless LAN), 1 port (for BLE) |
| Antenna configuration | 2×2 MIMO |
| 無線ボード | (1) Simultaneous use mode of 2.4 GHz/5 GHz band. (2) 5 GHz simultaneous use mode for both radio modules. (3) Simultaneous use mode for sensors (2.4 GHz or 5 GHz) and data communication (5 GHz). |
| Security | Stateful Firewalls IP filtering NAT 802.1x 802.11i WPA3 WPA2 WPA IPSec RADIUS Server |
| Dimensions. | 165mm×165mm×45mm |
| weight | 700g (main unit weight without external antenna) |
| Operating temperature | -20℃～+55℃ |
